Elbow, Inlet Manifold
Part No: V 01-5220-01
Pack of 1
V 01-5220-01: Elbow, Inlet Manifold – A 90-degree plumbing elbow casting built to connect to the inlet manifold, allowing space-saving right-angle pipeline integration at the pump intake port.
V 01-5220-01: Elbow, Inlet Manifold – A 90-degree plumbing elbow casting built to connect to the inlet manifold, allowing space-saving right-angle pipeline integration at the pump intake port.
Key Features
- Right-angle 90-degree plumbing elbow designed to steer intake liquid streams cleanly toward fluid caps.
- Features precision-machined connection faces to ensure tight, completely leak-free manifold block matching tracks.
- Hardened structural wall thickness resists physical wear and abrasive tracking erosion from fluid mixtures.
- Compact directional orientation layout optimizes valuable space routing footprints around pump base components.
- High-tensile steel or alloy construction provides immense clamping hold under continuous dynamic line forces.
Technical Specifications
| Manufacturer / Brand | Wilden |
| Component Classification | Metallic 90-Degree Fluid Suction Manifold Elbow |
| Primary Material | Heavy Die-Cast Structural Aluminum Alloy |
| Function | Routes incoming fluid from the central lower manifold into individual chamber check loops |
