ELBOW, INLET MANIFOLD
Part No: V 01-5220-21
Pack of 1
V 01-5220-21: ELBOW, INLET MANIFOLD – A 90-degree directional elbow casting for the suction intake line. It allows right-angle pipeline configuration at the lower manifold entry while minimizing internal fluid friction.
V 01-5220-21: ELBOW, INLET MANIFOLD – A 90-degree directional elbow casting for the suction intake line. It allows right-angle pipeline configuration at the lower manifold entry while minimizing internal fluid friction.
Key Features
- Variant series high-precision inlet routing elbow engineered for severe-duty utility environments.
- Heavy reinforced casting wall architecture safely handles continuous heavy pipeline pipeline loading strains cleanly.
- Retains superior physical shape memory, bore concentricity, and alignment across long processing runs.
- Non-reactive material structure resists corrosion scaling from atmospheric humidity or damp shop compressed air.
- Interlocking component blueprint layouts ensure perfect parallel matching along the central manifold axis loop.
Technical Specifications
| Manufacturer / Brand | Wilden |
| Component Classification | Premium Non-Metallic 90-Degree Fluid Suction Elbow |
| Primary Material | Solid PVDF (Kynar fluoropolymer matrix) |
| Operating Temperature | 10°F to 250°F (-12°C to 121°C) |
