CLAMP BAND, SMALL, NESTED
Part No: V 01-7100-03
Pack of 1
V 01-7100-03: CLAMP BAND, SMALL, NESTED – A high-strength nested small perimeter clamp ring assembly, used to securely lock exhaust plates, pilot valve boxes, or smaller manifold ends.
V 01-7100-03: CLAMP BAND, SMALL, NESTED – A high-strength nested small perimeter clamp ring assembly, used to securely lock exhaust plates, pilot valve boxes, or smaller manifold ends.
Key Features
- Interlocking small nested structure designed to secure compact manifold-to-chamber joints.
- Distributes radial compression forces evenly around perimeters to prevent localized seal leaks.
- High-tensile construction handles continuous cyclic pressure variations without structural relaxation.
- Low profile layout optimizes tight space routing envelopes around compact pump fluid sections.
- Heavy-duty protective surface coating locks out rust and scale inside damp factory environments.
- Heavy-duty oversized clamp band layout engineered to securely clamp massive fluid chambers.
- Distributes massive clamping loads uniformly to prevent high-pressure static gasket blowouts.
- High physical strength framing blocks component bowing or flexing under sudden line surges.
- Built to handle severe industrial settings, mechanical shocks, and ongoing factory room knocks.
- Standardized drop-in configuration accelerates field preventative updates to cut plant down-hours.
Technical Specifications
| Manufacturer / Brand | Wilden |
| Component Classification | Heavy-Duty Small Mechanical Segmented Clamping Band |
| Primary Material | Heavy Gauge 304 Stainless Steel |
| Structural Layout | Nested Structural Ridge Profile (Ensures perfect 360-degree perimeter contact) |
| Function | Securely fastens the manifold porting elbow sections onto the liquid chamber bodies |
| Manufacturer / Brand | Wilden |
| Component Classification | Heavy-Duty Chamber Perimeter Clamping Band |
| Primary Material | Heavy Gauge 304 Stainless Steel |
| Function | Interlocks the fluid chamber shell tightly to the center block to maintain dynamic pressure seals |
