WILDEN ®

Piston, Inner, UF

Part No: V 15-3760-08
★★★★★ New ● Out of Stock

Pack of 1

https://test.vistarb2b.com/web/image/product.template/4645/image_1920?unique=3b42cc8
Price
₹ 7,001.28 ₹ 4667.52
Quantity
Add to Cart
Buy Now

This combination does not exist.

👁 3572 Customers Visited 🛒 58 Customers Purchased 📦 232 Units Sold
🚚 Ships in 1–2 days
📄 GST Invoice
↩️ Non-returnable
📍 Check Delivery
Contact Us

Share

V 15-3760-08: Piston, Inner, UF – A specialized internal support plate engineered for pumps using Ultra-Flex (UF) series diaphragms, designed to reduce mechanical resistance and ease startup pressures.

V 15-3760-08: Piston, Inner, UF – A specialized internal support plate engineered for pumps using Ultra-Flex (UF) series diaphragms, designed to reduce mechanical resistance and ease startup pressures.

Key Features
  1. High-performance internal piston core pairing an advanced Ultra-Flex (UF) flexible geometry design with core pump specs.
  2. Upgraded flex geometry reduces internal stroke resistance to significantly lower pump operational startup air pressures.
  3. Spreads intense operational compression stresses uniformly to maximize running hours between service loops safely.
  4. Deep-seated structural guide boundaries prevent physical contact play during rapid linear mechanical shifts.
  5. Form-fit design matches original engineering templates perfectly to eliminate manual field adjustments.
Technical Specifications
Brand / ManufacturerWilden
Operating Temperature Limits-10°F to 200°F (-23°C to 93°C) high-frequency operations
Maximum System Pressure LimitsAbsorbs rapid mechanical changeover loads under fluid pressures up to 125 PSI (8.6 Bar)
Material Compliance StandardsHardened Carbon Steel / Clear Zinc Passivation layer
Dynamic Fluid Path Action & Intended ServiceProfiled exclusively to support thin-walled, hyper-responsive Ultra-Flex rubber diaphragms on large format 3-inch pump blocks
