Liquid Chamber,Cast iron
Part No: V 15-5000-02
Pack of 1
V 15-5000-02: Liquid Chamber,Cast iron – A rugged outer fluid chamber housing block manufactured from heavy die-cast cast iron alloy, designed to deliver exceptional strength in high-pressure or heavy utility environments.
V 15-5000-02: Liquid Chamber,Cast iron – A rugged outer fluid chamber housing block manufactured from heavy die-cast cast iron alloy, designed to deliver exceptional strength in high-pressure or heavy utility environments.
Key Features
- Heavy-walled fluid containment chamber constructed from premium Cast iron material matrix composition.
- Outstanding structural density and immense mass handle high pipeline backpressures and pipe strain variables safely.
- High-density casting framing handles rapid, high-pressure cyclic process shifts without dynamic fatigue cracks.
- Pre-aligned mounting bolt hole slots match original equipment templates perfectly for fast setup layouts.
- Wetted composition prevents wetted interior walls from rapid pitting when handling abrasive utility mixtures.
Technical Specifications
| Brand / Manufacturer | Wilden |
| Operating Temperature Limits | -20°F to 300°F (-29°C to 149°C) abrasive sludge workflows |
| Maximum System Pressure Limits | High-strength boundary rated to hold dynamic pipeline load peaks up to 125 PSI (8.6 Bar) |
| Material Compliance Standards | Cast Ductile / Gray Iron / Heavy industrial structural frame profile |
| Dynamic Fluid Path Action & Intended Service | High structural abrasion resistance outer fluid chamber; handles coarse mining tailing muds, raw effluent, and heavy abrasive slurries |
